Specifications
CRITERIA C-300 TAPE C-400 TAPE
Speed 10 cases per minute 8 cases per minute
Minimum Case Outer Dimensions
200 mm L x 150 mm W x 150 mm C
(7 7/8” L x 5 7/8” W x 5 7/8” C)
200 mm L x 150 mm W x 250 mm C
(7 7/8” L x 5 7/8” W x 9 7/8” C)
Maximum Case Outer Dimensions
500 mm L x 350 mm W x 600 mm C
(19 5/8” L x 13 3/4” W x 23 5/8” C)
620 mm L x 450 mm W x 650 mm C
(24 3/8” L x 17 3/4” W x 25 5/8” C)
Case Type RSC, HSC, FEFCO 0200/0201 RSC, HSC, FEFCO 0200/0201
Flute Type B, C, E B, C, E
Wall Type Single & Double Wall Single & Double Wall
Standard Sealing Device Lantech® TH-Series Tape Head Lantech® TH-Series Tape Head
Dimensions - Machine
2140 mm L x 2235 mm W x 1600
mm H
(84 1/4” L x 88” W x 63” H)
2310 mm L x 2375 mm W x 1600
mm H
(91” L x 93 1/4” W x 63” H)
Weight - Machine 525 kg (1155 lb) 575 kg (1265 lb)
Electrical Service Choices 3L-PE-400V-50Hz-Neutral
230V, 3-ph, 60Hz, Wye w/Ground
3L-PE-400V-50Hz-Neutral
230V, 3-ph, 60Hz, Wye w/Ground
Pneumatics 6 Bar (80 PSI) 6 Bar (80 PSI)
